Receiver Overview:
The Spektrum AR631+ AS3X+ Telemetry Receiver is a versatile, full-range 6-channel receiver designed for a wide variety of aircraft. Equipped with both AS3X+ and SAFE stabilization technology, it provides enhanced stability and control, countering the effects of wind, turbulence, and torque. With Smart telemetry capabilities, this receiver offers seamless integration with compatible Spektrum Smart ESCs for real-time data and requires minimal setup.
Ideal for both park flyers and larger sport models, the AR631+ includes a long 230mm antenna, ensuring flexible installation options for optimal signal reception. Bind effortlessly with the built-in bind button, eliminating the need for a bind plug, and enjoy advanced failsafe settings via forward programming from your Spektrum transmitter.
Note: The AR631+ receiver is not recommended for turbine-powered aircraft.
Features:
- Smart Transmitter File Download for easy updates
- 230mm antenna for versatile installation options
- Built-in AS3X+ Stabilization System with SAFE technology
- AS3X+ and SAFE setup via forward programming
- Ready to use with Spektrum Smart ESC for one-wire telemetry
- Streamlined, top-pin design in a lightweight hard-case
- Bind button for easy, plug-free binding
- DSMX protocol with DSM2 backward compatibility
- Fly-by range telemetry support
- Standard servo connectors
Specifications:
-
Application: Airplane, Sailplane
-
Modulation: DSMX
-
Band: 2.4GHz
-
Bind Method: Button
-
Channels: 6
-
Input Voltage: 3.5 - 9V
-
Technology: AS3X+, SAFE
-
Resolution: 2048
-
Length: 1.53in (39mm)
-
Width: 0.94in (24mm)
-
Height: 0.55in (14mm)
-
Weight: 0.28oz (8g)
Includes:
- (1) AR631+ 6-Channel AS3X+ & SAFE Receiver
- (1) Product Manual
